Designed to withstand extreme pressure, vibration, and temperature variations, hydraulic fittings are manufactured using high-strength materials such as stainless steel, carbon steel, and brass. They are available in a wide range of configurations including straight, elbow, tee, cross, and bulkhead fittings to suit diverse system requirements.
Ensures safe and leak-tight connection between tubes of different sizes
Provides high resistance to pressure, vibration, and corrosion
Easy to install and dismantle, requiring no special tools
Available in a variety of materials to suit different environments
Designed for efficient fluid transfer without flow restrictions
| Material Options | Stainless Steel 304/316, Brass, Carbon Steel, Duplex, Inconel, Monel, Alloy 20, etc.) |
| Connection Type | Tube-to-Tube (Different Sizes) |
| Pressure Rating | Up to 800 bar (depending on series – Low, Medium, High Pressure) |
| Size Range | From 1/16” to 2” OD tubes (or 6 mm to 38 mm metric sizes) with reduction combinations available |
| Temperature Range | Steel: –40°C to +120°C Stainless Steel –60°C to +400°C Brass:–60°C to +175°C |
| Standards | DIN 2353 / ISO 8434-1 |
| Applications | Hydraulic pipelines, Oil & Gas, Process Industries, Power Plants, Marine, and Chemical Processing Units |
